ocean_voyage_01 — Zone QA (CORRECTED)
Production coordinates overlaid on raw image. 1:1 with PDF canvas (800×593).Ship is LEFT. Text zone is RIGHT.
✕ SHIP EXCLUSION
x=0–54% (0–432px)
x=0–54% (0–432px)
TOP BRANDING — y=0–9% (53px)
BOTTOM FOOTER — y=88%+ (71px)
✓ TEXT ZONEx: 432–768px (54%–96%)y: 53–522px (9%–88%)width: 336px · height: 469px
x=54% (432px) →Production Coordinate Summary — CORRECTED
✓ Safe Text Zone (RIGHT side)
| Left (x) | 432px = 54% of 800 |
| Right edge | 768px = 96% of 800 |
| Width | 336px = 42% of 800 |
| Top (y, top-down) | 53px = 9% of 593 |
| Bottom stop (pdf-lib) | 71px from bottom |
| Writing height | 469px |
✕ Exclusion Zones
| Ship hull (LEFT) | x=0–432px (0%–54%) |
| Right edge buffer | x=768–800px (96%–100%) |
| Top branding | y=0–53px (0%–9%) |
| Bottom footer | y=522–593px (88%–100%) |
✓ CORRECTED: Ship hull occupies LEFT (0–54%). Text zone is RIGHT open sky/ocean (54%–96%).
PDF canvas: 800×593px (scale = 800/1620 = 0.494)
Functions updated: initiateLetterDelivery + processScheduledLetters + backgroundTemplatesExtended.js
